WEW-300D Computer Display Hydraulic Universal Testing Machine
Price advantage
We increase our own research and development efforts, built processing center, produce the core parts independently, so we could reduce link costs with the same quality. Our good quality products could save you much more than some other low price but bad quality products. Reducing the failure rate of the machine to reduce the customer's maintenance costs, but also improve the efficiency of the machine, this price with high quality could give customers real benefits.
Service advantages
A full range of services making customer satisfaction reflect our professional. Pre-sale, we provide comprehensive advisory services, tailored for different industries to meet customers’ special needs. After-sale, we could supply door to door installation and training services according to customer requirements . During the use process, if there is any problem, your could reach our technical engineers in time by e-mail, remote video, telephone and other possible ways. The machine parts is free of charge during the warranty period ,and machines lifetime maintenance.
The machine adopts hydraulic loading, Computer Display, easy and convenient to operate. It is mainly used to execute the tension, compression, bending, flexural etc. test for metal materials. Attached with simple accessories and devices, it can be used to test wood, concrete, cement, rubber, and so on.It is very suitable for making test to different metal or nonmetal materials under high toughness and hardness against extreme big loading force.
ISO6892, BS4449,ASTM C39,ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards.
The oil cylinder is at the bottom of the load frame,tension space is at the upside and compression &bending spaces are between lower crosshead and working table.It is adopting oil hydraulic power to push the piston in the oil cylinder to provide loading force.The lower crosshead is driven by motor throng decelerator,chain transmission device and screw pair to realize the adjustment of testing space.
The machine adopts oil pressure transducer to measure load and use photoelectric encoder to measure the displacement.The computer is timely collecting the testing parameters like loading force,stroke etc. Our win WEW software based on windows systems is able to display the load,load peak value,deformation,testing curves etc.very easily,and can make automatic calculating of test results,i.e. Tensile strength,up/low yield strength,Non proportional stress point etc,Report creation function makes it is very simple to make testing report in your needed format.
6.1 Full computer displayed of testing process.
6.2 Manual loading speed will meet your appropriate testing speed.
6.3 Stable and reliable high intensity 4 columns and 2 reeling screw columns structure load frame.
6.4 Timely display software will provide accurate record of testing process.
6.5 Adopt oil-hydraulic automatic clamping
6.6 Export guide will create your testing report very easily.
6.7 Overload protection will secure operators.
| Model | WEW-300D |
| Structure | 4 columns and 2 screws，full protection,main oil cylinder setting down |
| Control way | loading process manual control,computer automatic data dealing |
| Max.load (kN) | 300kN |
| Accuracy Grade | 1 Grade |
| Measuring range | 2%-100%FS |
| Value error | ±1% of showing value |
| Beam moving speed | 220mm/min |
| Piston max speed | 300mm/min |
| Max.piston stroke(mm) | 250mm |
| Max. tension test space | 750mm (can customize) |
| Max.Compression Test Space | 600mm (can customize) |
| Column clearance(mm) | 485mm |
| Clamping method | Hydraulic clamping automatically |
| Round specimen clamping Dia (mm) | Φ10-Φ32mm, (Φ4-Φ10mm Optional ) |
| Flat specimen clamping thickness (mm) | 0-15mm (15-30mm Optional) |
| Flat specimen clamping width(mm) | 80mm |
| Compression plate size (mm) | Round Dia φ160mm,bottom plate w/spherical adjustment |
| Main machine Size | 745*685*1905mm |
| Controlling oil source size | 632*650*1340mm |
| Power supply | 3-phase,AC380V, 50Hz（can be customized） |
| Item |
Quantity |
Remarks | Picture | ||
| Host | |||||
| High strength main unit |
1 set |
four screws and two columns | |||
| Tensile fixture (Round Jaw) |
Each 1 set |
Φ10-Φ20,Φ20-Φ32mm Φ4-Φ10mm(optional) |  |
||
| Tensile fixture (Flat Jaw) |
1 set |
0-15mm,15-30mm optional |  |
||
| Compression fixture |
1 set |
Ф160mm |  |
||
| Bending fixture |
1 set |
Pressure Head: Φ30mm |  |
||
| Shear fixture |
1 set |
optional |  |
||
| Foundation bolt |
4 set |
 |
|||
| Oil pressure sensor |
1 set |
 |
|||
| Linear photoelectric encoder |
1 set |
 |
|||
| Oil source control cabinet | |||||
| Computer display Oil Sources |
1 set |
Desktop | |||
| Oil pump |
1 set |
Italy imported Marzocchi |  |
||
| Control System | |||||
| Control PC |
1set |
Lenovo famous brand
|
 |
||
| Printer |
1set |
HP |  |
||
| Special data acquisition card |
1 suit |
LAIHUA English language |  |
||
| Extensometer |
1set |
 |
|||
| Control software |
1 suit |
||||
| Hand Control Box |
1set |
||||
